The TD006-C is a pivot hinge engineered for a sleek, concealed installation, capable of supporting doors up to 500 kg (1102 lbs) with 360-degree rotation for added flexibility. Made from high-quality, corrosion-resistant materials, our durable and customizable hinges enhance safety and convenience, making them the ideal choice for both residential and commercial projects featuring slim doors.
500 kg (1102 lbs)
171.5 x 44 x 32mm (6.7 x 1.7 x 1.2 inches)
40 mm (1.574 inches)
Side and middle
70 mm (2.755 inches)
15 mm (0.590 inches)
360°
For wood, aluminum frames and framed glass, massive cladded doors
Made in stainless steel, aluminum alloy
Working cycles: up to 1,000,000
Free Swing:✓
Single Acting (90° rotation):✓
Double Acting (360° rotation):✓
Hold positions: None
Axial/Plumb Adjustment + /– 5mm
