The C121-D is a pivot hinge designed with a premium stainless steel base that is corrosion-resistant and equipped with roller bearings for enhanced stability. While the adjustable design allows for customizable force and closing speed, the automatic return function ensures effortless and reliable closing.
60 kg (132 lbs)
2800 x 950 mm (110.2 x 37.4 inches)
32 mm (1.259 inches)
60 kg (132 lbs)
360°
For wood, aluminum frames
Made in stainless steel, zinc alloy
Double Acting (360° rotation):✓
Automatic Return (≤90°):✓
Soft close:✓
Hold positions (90°): ✓
Allows for easily continuous adjustment in 2 dimensions
Depth : + /– 2 mm
Side: + /– 2 mm
