C116

The C116 is a concealed hinge that provides a sleek new-opening experience. This adjustable hinge allows seamless connection of door panels without distinguishing between left or right, ensuring flexibility. With quiet operation and pivot rotation for concealed openings, it enhances the overall aesthetics of your space.

Product Detail

Specifications

Weight Capacity:

70 kg (154 lbs)

Max. Door Dimensions:

2400 x 1000 mm (94.4 x 39.3 inches)

Min. Door Thickness:

40 mm (1.574 inches)

Opening Angle:

110°

Features

For wood, aluminum frames

Made in zinc alloy

Allows for easily continuous adjustment in 2 dimensions

Depth : + /– 1.5 mm

Side: + /– 3 mm
